Products can be handled

Cola, carbonated water, soda water, etc.

Containers can be handled

PET bottles with various volumes and shapes

Filling system

Isobaric filling

Capacity

5000BPH—40000BPH

Technical features:

Adopt technology of air conveyor direct connect with bottle infeed starwheel and neck handling technology to convey bottles.

High speed filling line adopts bottle gripper conveying technology. It is free to change over bottle size and the working table inside the machine is more laconic.

By 3-in-1 monoblock, the bottle goes through rinsing, filling and capping with little abrasion, and the transferring is stable, bottle changing is easier.

Specially designed stainless steel bottle gripper dose not contact the thread parts of the bottle neck, avoiding the second contamination.

Pressure liquid carousel. High speed line adopts annular liquid carousel.

High speed and mass flow filling valve enssures the high filling speed and exact fluid level.

Parts contacting liquid are all made of excellent stainless steel or food grade engineering plastic. The electric system is from international brand and achieves the national food hygienic standard.

The bottle-out starwheel is helical structure. While changing over bottle size, it is no need to adjust bottle-out conveyor height.
